Best Hydraulic Plate Compactor for excavators
Jiangtu hydraulic plate compactor is a kind of excavator attachments which is used to compress some types of soil and gravel for construction projects that require a stable subsurface.
Application
JIANGTU hydraulic plate compactor excavator is used for the leveling of high-speed way and railway slopes, roads, construction sites, and building floors.
Product Description
Jiangtu hydraulic plate compactor is a kind of excavator attachments which is used to compress some types of soil and gravel for construction projects that require a stable subsurface.
As one of the leading hydraulic plate compactor manufacturers in China, JIANGTU has a full range of compactors for excavators from 1.5-40 tons.They are suitable for all kinds of brands and models of excavators.
APPLICATION
JIANGTU hydraulic plate compactor excavator is used for the leveling of high-speed way and railway slopes, roads, construction sites, and building floors.
Please check the following specifications to choose the right hydraulic plate compactor model.
| Hydraulic Plate Compactors | ||||||
| Category | Unit | JT-mini | JT-02/04 | JT-06 | JT-08 | JT-10 |
| Height | mm | 435 | 530 | 650 | 720 | 730 |
| Width | mm | 442 | 550 | 700 | 900 | 900 |
| Impulse force | ton | 3 | 4 | 6.5 | 11 | 15 |
| Vibration frequency | rpm/min | 2000 | 2000 | 2000 | 2200 | 2200 |
| Oil flow | l/min | 30-60 | 45-85 | 85-105 | 120-170 | 120-170 |
| Operating pressure | kg/cm² | 100-130 | 100-130 | 100-150 | 150-200 | 150-200 |
| Bottom measurement | mm | 800*442 | 900*550 | 1160*700 | 1300*900 | 1500*1000 |
| Excavator weight | ton | 2-4 | 4-10 | 12-16 | 18-24 | 30-40 |
| Weight | kg | 200 | 350-500 | 650-800 | 900-1000 | 1100-1300 |
| Mortor Model | Brand PERMCO | 1221081B39 | 1221081B39 | 1215071138 | 1215071048 | M7600-F100NK7676G2 |
| Mortor Displacement | ml/rev | 25.39 | 25.39 | 63.2 | 84.3 | 100 |
♥ The Specifications of this equipment are subject to change for improvements.
Excellent performance with high durability. The company has been developed to meet the high standards of the current market. The demand for high durability and low maintenance costs on hydraulic equipment are combined in the total design of our hydraulic plate compactors.
Related Articles
What is a hydraulic plate compactor for excavator?How does it work?How to choose?
Main Features of JIANGTU Hydraulic Plate Compactor for sale
1. Useful for road construction, foundation & backfill;
2. Japan-made NTN swing bearing, PERMCO motor, EVERPADS rubber, Italy-made relief valve;
3. Longer lifetime of rubber pads;
Main Advantages of JIANGTU hydraulic plate compact excavator for sale:
- Vibration frequency of Hydraulic Plate Compactor
The motor and bearing JIANGTU uses are originally imported, with a speed of up to 6000 RPM, while others in the market are roughly 2000-3000RPM。 High-quality accessories bring high work efficiency, the striking frequency of Jiangtu Hydraulic Plate Compactor can reach up to 1000 per minute, the striking speed is fast and the strength is strong so that its similar products can not be matched.
- Wear-resistant plate
One of the important components of the Hydraulic Plate Compactor, Jiangtu uses imported wear-resistant plates. The material and thickness are above average and will not deform after long-term use. Poor quality wear-resistant plates will have "symptoms" of different thicknesses after a short period of use, but Jiangtu's Hydraulic Plate Compactor will not have such "symptoms".
Wear-resistant-plate-JIAGNTU-hydraulic-plate-compactor-for-excavator
- Rotation function
The Jiangtu Hydraulic Plate Compactor can rotate 90°to help you hit no dead corners, such as corners, walls, and other ordinary difficult-to-hit places, we have a rotation function that can let you easily cope with various working conditions.
- Valve core
Jiangtu Hydraulic Plate Compactor is equipped with a throttle valve and a safety valve， the function of the throttle valve is to control this valve to limit the output frequency. The safety valve is used to protect the product during use. These two valve configurations are exclusive to Jiangtu.
How to choose a high-quality hydraulic plate compactor for your excavator?
1. Check the company’s qualifications and strengths making sure the quality is guaranteed.
2. Check the company’s technical team making sure the products are safe enough.
3. What kind of after-sales service do they provide? few faults? easy to operate?
4. Ensure that it matches your excavator well.
Why choose us ？
1. As the leading hydraulic plate compactor manufacturers in China, we have 10 years experience in Hydraulic plate compactors developing and manufacturing.
2. R&D department，with 6 professional engineers and more than 40 skilled workers.
3. Strict QC system, ISO9001:2008 and CE certificate.
4. 12 months warranty after receiving the product, 6 months free replacement.
5. The OEM/ ODM customization service is available.
Our Certificate
Through 10 years’digging in research and development, Jiangtu Company achieved more than 20 patents such as invent/design patent successively and received CE, ISO and SGS certificates from 2012 to 2019 and now started a new chapter to explore the global market.
Our Exhibition
Jiangtu Company had attended Bauma China/Russia Exhibitions continuously, where we met many global dealers and end-users, who thought highly of our products both in appearance and performance.
Our Team
Aiming to deliver practical, easy-to-use and durable excavator attachments for the global market, our R&D team size keeps growing. Currently, there are 6 professional engineers with an average researching experience of 4 years to meet customization demands. More than 40 skilled technicians have made it possible to guarantee the lead time and delivery date.
Our Service
1. We can offer a comprehensive range of excavator plate compactors, hydraulic plate compactors for mini-excavator, plate compactor attachment excavator, etc...
2. Of course, You may rest assured that all of our products can be supplied in a wide range of designs, and the product can be customized according to your personalized requirements to meet your requirements. Meanwhile, we can offer an excellent after-sale service.
3. Your business relationship with us will be confidential to any third party.
4. We promise to reply to you upon receipt of your inquiry within 12 hours.
5. The order will be produced exactly according to order details and proofed samples, our QC will submit the inspection report before shipment.
OEM
1. Offer your design documents or let our design team work out some concepts for choosing.
2. We will always provide you with a virtual pre-production proof that shows the exact placement of your logo on the product.
Packaging details
Port: Qingdao, Yantai, Shanghai, etc.
Packing Type: Standard export packages.
JIANGTU hydraulic plate compactors, produced by the factory, price concessions, direct shipment from the manufacturer, minimum order of one piece, can be sent worldwide, click for a quotation
FAQS
Question:Which country have you been exported?
Russia, USA, Canada, Japan, Korea, Malaysia, Hong Kong, Taiwan, India, Indonesia, Australia, New Zealand, Israel, South Africa etc.
Question:How about the Shipment?
Shipment can be made by sea, air or land. Sea loading ports include Qingdao, Yantai and Shanghai etc. Sales manager will select an optimal shipping method for you. For more information, please contact with customer service staff.
Question:How about the package?
Our attachments are packaged by standard export wooden cases free from fumigation.
Question:How about delivery time?
Usually 15 days subject to order quantity. Due to the surge in orders, please check with customer service staff for lead time.
Question:What’s the MOQ and payment terms?
MOQ is 1 set. Payment by T/T, L/C, Credit Card, and Western Union is acceptable. Other payment method can be negotiated.
Question:Can I customize a product?
Sure, we can provide OEM and ODM service.
Question:Are you sure your product will fit my excavator?
Yes, we are professional attachments manufacturer, We make attachments according to your excavator bucket dimensions.
Question:Are you a manufacturer?
Yes, our factory was established in 2011.
